Identification method
1：N/1：1 comparison
Recognition speed
＜1 second
Communication interface
USB2.0、UART
Working voltage
DC 5.0V（±0.5V）or DC 3.3V (±0.3V)
Working current
＜27.5mA/5V or ＜27.5mA/3.3V
Standby current
＜4uA
Power management mode
capacitor induction power on, system startup time＜10mS
Working environment
temperature：-20℃～60℃ humidity：20%～80%RH
? Product Features:
● Exclusive finger vein module can be matched with fingerprint protocols
● Fast power-on speed, extremely low power consumption, the smallest volume in China
● Ultra-thin finger vein smart lock module, the total thickness is less than 14.7mm
● The lock handles of which The thickness space is greater than 8.7mm are all fit
● Waterproof, no dust and water accumulation, no need for cleaning and maintenance
? Function extension:
● Full duplex serial port TTL level supports extended SPI mode
● Support extended PWM voice output
? Industrial design:
● Adopt dustproof and waterproof design, IP65 protection grade
● The camera lens adopts multi-mode and multi-layer high-transparent glass design , effectively suppress distortion and stray light interference
? Applications:
● Fully automatic intelligent lock, intelligent door handle, small terminal
